DKM10A-05 DC/DC Converter 9-18V:+/-5V 1A 10W, MEAN WELL
MEAN WELL DKM10 Series Description:
The DKM10 series are isolated and regulated module DC-DC converters in a DIP 1"x1" case. They have international standard pins, offer high efficiency (up to 90%), wide operating temperature range (-40~+85°C), 1.5KVDC I/P-O/P isolation voltage, conformity to BS EN/EN55032 ( radiation protection class A without additional components), protection against short circuit in continuous mode, etc. The models can work with different input voltages (4.7~9V, 9~18V, 18~36V and 36~72V 2:1 wide input range) and allow different output voltages (3.3V/5V/12V/15V for single output and ±5V±12V/±15V for dual output). Therefore, the products are suitable for various systems and applications, such as industrial control, telecommunica
