LRS-100-5 Switching power supply, closed, 90W, 5V, 18A, MEAN WELL
zoom_out_map
chevron_left chevron_right


Advertising [AfterProductThumbs]

New

LRS-100-5 Switching power supply, closed, 90W, 5V, 18A, MEAN WELL

LRS-100-5 Switching power supply, closed, 90W, 5V, 18A, MEAN WELL

€14.33 Tax included

€14.33 Tax excluded

check 609


Advertising [ProductAdditionalInfo]

local_shipping FREE shipping on orders over $25.00 shipped by Amazon. Details


Advertising [Product3rdColumn]

Security policy
Site hosted and secured in Eu.
Delivery policy
Packages transported with the service of Bpost, DpD, PostNl or your own carrier.
Return policy
Defective devices (not electronic components) are (according to the manufacturer's warranty) exchanged or repaired.

Meanwell LRS-100 Enclosed Power Supply Series Description:

LRS-100 series is composed of 100W single-output enclosed-type power supplies with a 30mm low profile design. Having an input range of 85~264VAC, the entire series provides various output voltages (3.3V, 5V, 12V, 15V, 24V, 36V and 48V). In addition to the high efficiency of up to 91%, the design of metallic mesh case enhances heat dissipation of the LRS-100 series, thus the whole series can operate from -30°C to 70°C under air convection without a fan. Delivering an extremely low no load power consumption (less than 0.3W), it allows the end system to easily conform to worldwide energy requirements. The LRS-100 series features extensive protection functions and a 5G antivibration capability. Consequently, the series complies with international safety regulations such as BS EN/EN2368-1, BS EN/EN60335-1,BS EN/EN61558-1/-2-16, UL62368-1 and GB4943. The LRS-100 series offers an unattained price-to-performance ratio and is the ideal power supply solution for various industrial applications.

Meanwell LRS-100 Enclosed Power Supply Series Features:

  • enclosed design (case), screw terminals
  • universal input
  • overload protection by shutdown (hiccup), auto recovery
  • protected against short circuit, overload, overvoltage
  • low height
  • cooling by free air convection
  • withstands 5G vibration test
  • Power consumption at no load<0.3W
  • Overvoltage category Ill
  • High operating temperature of up to 70°C
  • High efficiency, long life and high reliability
  • Safety standards: UL/EN62368-1
  • EMC standards: EN55032 Class B and others
  • 3 years manufacturer warranty

Meanwell LRS-100 Enclosed Power Supply Series Applications:

  • Industrial Automation
  • Industrial control systems
  • Mechanical and electrical devices
  • Household appliances

Notice:

This product is intended for installation in terminal equipment.
For detailed technical specifications, please check the data sheet in the "downloads" section.
MEAN WELL
LRS-100-5
609 Items
4021087027915
LRS-100-5
