LRS-35-36 Switching power supply, closed, 36W, 36V, 1A, MEAN WELL
zoom_out_map
chevron_left chevron_right


Advertising [AfterProductThumbs]

LRS-35-36 Switching power supply, closed, 36W, 36V, 1A, MEAN WELL

LRS-35-36 Switching power supply, closed, 36W, 36V, 1A, MEAN WELL

€10.70 Tax included

€10.70 Tax excluded

check 73


Advertising [ProductAdditionalInfo]

local_shipping FREE shipping on orders over $25.00 shipped by Amazon. Details


Advertising [Product3rdColumn]

Security policy
Site hosted and secured in Eu.
Delivery policy
Packages transported with the service of Bpost, DpD, PostNl or your own carrier.
Return policy
Defective devices (not electronic components) are (according to the manufacturer's warranty) exchanged or repaired.

Meanwell LRS-35 Enclosed Power Supply Series Description:

The LRS-35 series consists of 35W single output power supplies with an enclosed design and a 30mm low profile design. The entire series operates with an input voltage range of 85-264VAC and offers various output voltages (5V, 12V, 15V, 24V, 36V and 48V). In addition to the high efficiency of up to 89%, the metal grid package design improves the heat dissipation of the LRS-35 series, allowing the entire series to operate from -30°C to 70°C under air convection without a fan. The ultra-low idle power consumption (less than 0.2W) allows the final system to easily meet worldwide power requirements. The LRS-35 series has extensive protection features and a 5G anti-vibration function. Consequently, the series complies with all international safety regulations such as BS EN/EN2368-1, BS EN/EN60335-1, BS EN/EN61558-1/-2-16, UL62368-1 and GB4943. The LRS-35 series offers unprecedented value for money and is the ideal power supply solution for various industrial applications.

Meanwell LRS-35 Enclosed Power Supply Features:

  • enclosed design (case), screw terminals
  • universal input
  • overload protection by shutdown (hiccup), auto recovery
  • protected against short circuit and overvoltage
  • low height
  • cooling by free air convection
  • withstands 5G vibration test
  • power consumption at no load<0.2W
  • overvoltage category Ill
  • high operating temperature of up to 70°C
  • high efficiency, long life and high reliability
  • safety standards: EN62368-1
  • EMC standards: EN55032 Class B and others
  • 3 years manufacturer warranty

Meanwell LRS-35 Enclosed Power Supply Applications:

  • Industrial automation
  • Industrial control systems
  • Mechanical and electrical devices
  • Household appliances

Notice:

This product is intended for installation in terminal equipment.
For detailed technical specifications, please check the data sheet in the "downloads" section.
