MPM-45-15ST Switching power supply, module, 45W, 15V, 3A screw terminal, MEAN WELL
zoom_out_map
chevron_left chevron_right


Advertising [AfterProductThumbs]

New

MPM-45-15ST Switching power supply, module, 45W, 15V, 3A screw terminal, MEAN WELL

MPM-45-15ST Switching power supply, module, 45W, 15V, 3A screw terminal, MEAN WELL

€23.95 Tax included

€23.95 Tax excluded

check 10


Advertising [ProductAdditionalInfo]

local_shipping FREE shipping on orders over $25.00 shipped by Amazon. Details


Advertising [Product3rdColumn]

Security policy
Site hosted and secured in Eu.
Delivery policy
Packages transported with the service of Bpost, DpD, PostNl or your own carrier.
Return policy
Defective devices (not electronic components) are (according to the manufacturer's warranty) exchanged or repaired.

Meanwell MPM-45 AC/DC Modular Power Supply Series Description:

MPM-45 series consists of 45W powerful and small (87*52*29.5mm) AC/DC module power supplies for medical applications. They operate in a voltage range of 80~264VAC, have low no-load power consumption (less than 0.1W), high efficiency up to 92.5%, Class II double insulation (without FG), excellent heat dissipation, withstand 2-5G vibration, provide high EMC performance and have 4KVAC insulation. The design complies with IEC/BS EN/EN60601-1 and ANSI/AAMI ES60601-1 version three with 2xMOPP levels and offers extremely low leakage current. The series is perfect for BF (patient contact) type medical devices or similar applications.

Meanwell MPM-45 AC/DC Modular Power Supply Series Features:

  • enclosed design, PCB mounting
  • universal input
  • up to 50W peak power for 10 seconds
  • overload protection by shutdown (hiccup), auto recovery
  • protected against short circuit and overvoltage
  • Safety standards: EN60601-1
  • EMC standards: EN55011 class B
  • 3 years manufacturer warranty
  • MPM-45-_: PCB mounting
  • MPM-45-_ST: Screw terminals

Meanwell MPM-45 AC/DC Modular Power Supply Series Applications:

  • Portable medical devices
  • Medical computer monitors
  • Mobile clinic workstations
For detailed technical specifications, please check the data sheet in the "downloads" section.
MEAN WELL
MPM-45-15ST
10 Items
MPM-45-15ST
