HLG-120H-54B LED driver, IP67 124.2W, 54V, 2.3A CV+CC dimmable, MEAN WELL

HLG-120H-54B LED driver, IP67 124.2W, 54V, 2.3A CV+CC dimmable, MEAN WELL

€47.77 Tax included

€47.77 Tax excluded

check 33


Advertising [ProductAdditionalInfo]

local_shipping FREE shipping on orders over $25.00 shipped by Amazon. Details


Advertising [Product3rdColumn]

Security policy
Site hosted and secured in Eu.
Delivery policy
Packages transported with the service of Bpost, DpD, PostNl or your own carrier.
Return policy
Defective devices (not electronic components) are (according to the manufacturer's warranty) exchanged or repaired.

Meanwell HLG-120H LED drivers Series Description:

The HLG-120H Series of LED drivers provide constant current for various LED lighting applications. They act as an independent power supply and feature a wide range of input options. Their metal housing adds durability, whereas overload protection by current limiting and auto recovery prevents damage to the device. The drivers are also protected against short circuits, overvoltages, and overtemperature and feature a built-in PFC circuit. The HLG-120H Series complies with SELV, EN61347-1, EN61347-2-13 safety standards and EN55015, EN61000-3-2 Class C, EN61000-3-3, EN61547 EMC standards. The Manufacturer Meanwell also offers an extensive 7 year manufacturer warranty.

Meanwell HLG-120H LED drivers Series Features:

  • constant current
  • independent power supply
  • Wide range input
  • metal housing
  • overload protection by current limiting, auto recovery
  • protected against short circuit, overload, overvoltage, overtemperature
  • built-in PFC circuit
  • for LED lighting applications
  • SELV Compliant
  • Safety standards: EN61347-1, EN61347-2-13 and others
  • EMC Standards: EN55015, EN61000-3-2 Class C, EN61000-3-3, EN61547 and others
  • 7 years manufacturer warranty
  • HLG-120H-: IP67, voltage and current fixed preset, not dimmable
  • HLG-120H-A: IP65, output voltage and current limitation adjustable via internal potentiometer, not dimmable
  • HLG-120H-B: IP67, dimming via implemented control line, 3 in 1 dimming function (1...10V DC, PWM, 100k Ohm potentiometer)
  • HLG-120H-AB: IP65, output voltage and current limitation adjustable via internal potentiometer, dimming via implemented control line, 3 in 1 dimming function (1...10V DC, PWM, 100k Ohm potentiometer)

Notice:

Power supply for the operation of LED light sources. This product is not designed for operation in no-load status.
For detailed technical specifications, please check the data sheet in the "downloads" section.
