NDR-75-12 DIN rail power supply, 75W, 12V, 6.3A, MEAN WELL
zoom_out_map
chevron_left chevron_right


Advertising [AfterProductThumbs]

New

NDR-75-12 DIN rail power supply, 75W, 12V, 6.3A, MEAN WELL

NDR-75-12 DIN rail power supply, 75W, 12V, 6.3A, MEAN WELL

€21.18 Tax included

€21.18 Tax excluded

check 759


Advertising [ProductAdditionalInfo]

local_shipping FREE shipping on orders over $25.00 shipped by Amazon. Details


Advertising [Product3rdColumn]

Security policy
Site hosted and secured in Eu.
Delivery policy
Packages transported with the service of Bpost, DpD, PostNl or your own carrier.
Return policy
Defective devices (not electronic components) are (according to the manufacturer's warranty) exchanged or repaired.

Meanwell NDR-75 DIN Rail Power Supply Series Description:

The NDR-75 series consists of low-cost, compact 75W DIN rail power supplies that can be mounted on TS-35/7.5 or TS-35/15 DIN rails. The enclosure is only 32mm wide, saving space in control cabinets. The entire series has an input range of 90VAC to 264VAC and complies with BS EN/EN61000-3-2. The NDR-75 series features a metal housing that improves the unit's heat dissipation. With an efficiency of up to 89%, the entire series can operate at an ambient temperature between -20°C and 70°C under air convection. It is equipped with a constant current mode for overload protection, making it ideal for various inductive or capacitive applications. Since the NDR-75 series provides all relevant protection features and meets all relevant certifications for industrial control applications (UL508, BS EN/EN62368-1, etc.), it is a very competitive power supply solution for industrial applications.

Meanwell NDR-75 DIN Rail Power Supply Series Features:

  • direct DIN rail mountable (TS-35/7.5 or 15)
  • closed design, screw terminals protected against accidental contact
  • cooling by free air convection
  • universal input
  • overload protection by current limiting, auto-recovery
  • protected against short circuit and overvoltage
  • LED indication for DC OK

Meanwell NDR-75 DIN Rail Power Supply Series Applications:

  • Industrial control system
  • Factory automation
  • Electro-mechanical devices

Notice:

The power supply is designed for installation in final equipment.
For detailed technical specifications, please check the data sheet in the "downloads" section.
MEAN WELL
NDR-75-12
759 Items
4021087019682
NDR-75-12
